Product Overview
Sanlita’s 100kWh outdoor all-in-one high-voltage battery storage cabinet is specifically engineered for commercial and industrial (C&I) applications, including factories, warehouses, and commercial buildings. This turnkey solution integrates a high-voltage LFP battery pack, hybrid inverter, energy management system (EMS), and thermal management into a single, weatherproof enclosure. It enables peak shaving, load shifting, backup power, and solar self-consumption optimization, helping businesses reduce electricity costs and enhance energy resilience.
Technical Specifications
| Parameter | Value |
|---|---|
| Rated Energy Capacity | 100 kWh (expandable) |
| Battery Chemistry | LiFePO4 (LFP) |
| Nominal Voltage | 716.8 V (high-voltage) |
| Usable Capacity | ≥ 90% |
| Cycle Life | ≥ 6000 cycles @ 80% DOD |
| Inverter Power | 50 kW (AC output) |
| Enclosure Rating | IP54 (outdoor) |
| Operating Temperature | -20°C to +55°C |
| Cooling Method | Intelligent forced air + HVAC |
| Communication | RS485, CAN, Ethernet, 4G (optional) |
| Certifications | CE, UN38.3, IEC 62619, UL 1973 (pending) |
| Dimensions (W×D×H) | 1200 × 800 × 2000 mm |
| Weight | ~1200 kg |
Why Choose Sanlita
As a leading Chinese manufacturer with over 15 years of experience in energy storage, Sanlita offers unmatched value: Factory-direct pricing with no distributor markups; Customizable solutions for voltage, capacity, and communication protocols; Rigorous quality control with 100% factory testing before shipment; Global logistics support and fast delivery; and Comprehensive after-sales service including remote monitoring and 5-year warranty.
FAQ
Q: What is the typical payback period for this 100kWh system in a factory?
A: Depending on local electricity rates and usage patterns, most factories achieve a payback period of 3-5 years through peak shaving and solar self-consumption.
Q: Can this cabinet be connected to existing solar PV systems?
A: Yes, the integrated hybrid inverter supports both AC and DC coupling with new or existing solar PV arrays, making retrofitting easy.
Q: Is the battery cabinet safe for outdoor installation in extreme weather?
A: Absolutely. The IP54-rated enclosure protects against dust and water splashes, and the built-in HVAC system maintains optimal battery temperature from -20°C to +55°C.
Q: What is the warranty and expected lifespan?
A: Sanlita offers a standard 5-year warranty, with an expected design life of over 10 years (or 6000 cycles) for the LFP battery.
Q: How long does installation take?
A: The all-in-one design allows for plug-and-play installation within 1-2 days by a certified electrician, including grid connection and EMS configuration.
